VS-161H - Operating the VS-161H 16x1 HDMI Switcher 15
2. Press the PANEL LOCK button while turning the POWER on again.
The INPUT buttons flash simultaneously.
3. Keep pressing and holding the PANEL LOCK button for a few seconds and
then release it.
The PANEL LOCK button flashes. If an input button lights this indicates that
that input is set to the DVD mode. If no input button lights this indicates that
that input is set to the PC mode.
4. Toggle between the PC mode (input button not lit) and the DVD mode (input
button lights) by pressing that input.
5. Press the PANEL LOCK button to exit this mode.
6. You can connect a computer to the input(s) that is set to the PC mode and a
DVD to the input(s) that is set to the DVD mode.
The following table summarizes the differences between the PC mode and the
DVD mode.
PC Mode DVD Mode
The input is connected to a
computer
The input is connected to a multimedia application, such as a
DVD, a set top box and so on
The EDID is available at all times
(to prevent computer reset)
The EDID is available only when that input is connected to an
output
The input EDID source is the
default EDID or an acquired EDID
(see
Section 6.2
The input EDID source is acquired directly from the connected
output
)
6.2 Acquiring the EDID
The acquired EDID is used when an input is set to the PC mode.
To acquire the EDID:
1. Turn the POWER off.
2. Press the PANEL LOCK button and the INPUT 16 button while turning the
POWER on again.
The INPUT buttons flash in sequence until the unit has completed reading
the EDID.
