VS-161H - Connecting the VS-161H 16x1 HDMI Switcher 11
5.2.1 Configuring the Ethernet Port
After connecting the Ethernet port, you have to install and configure it.
For detailed instructions on how to install and configure your Ethernet port, see the Ethernet
Configuration (FC-11) guide.pdf on our Web site at http://www.kramerelectronics.com .
5.2.2 Connecting the Ethernet Port directly to a PC
You can connect the Ethernet port of the VS-161H to the Ethernet port on your PC
via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identification of the factory
default IP Address of the VS-161H during the initial configuration
After connecting the Ethernet port, configure your PC as follows:
1. On your desktop, right-click the My Network Places icon.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears.
5. Select the Internet Protocol (TCP/IP) and click the Properties Button (see
Figure 5 ).
