Communication Parameters
36
11 Communication Parameters
Table 5 lists the communication parameters as used in Kramer Electronics
products.
Table 5: Communication Parameters
EDID
EDID data is passed between Output 1 and Input 1
RS-232
Protocol 2000 Protocol 3000 (Default)
Baud Rate: 9600 Baud Rate: 115,200
Data Bits: 8 Data Bits: 8
Stop Bits: 1 Stop Bits: 1
Parity: None Parity: None
Command Format: HEX Command Format: ASCII
Example (Output 1 to Input 1): 0x01, 0x81, 0x81, 0x81 Example (Output 1 to Input 1): #AV 1>1
Switching Protocol
P2000 -> P3000 P3000 -> P2000
Command: 0x38, 0x80, 0x83, 0x81 Command: #P2000
Front Panel: Press and hold Output 1 and
Output 3 simultaneously
Front Panel: Press and hold Output 1 and
Output 2 simultaneously
Ethernet
Default Settings Reset Settings
IP Address: 192.168.1.39 Power cycle the unit while holding in the Factory Reset button, located on
the rear panel of the unit.
TCP Port #: 5000
UDP Port #: 50000
12 Table of ASCII Codes for Serial Communication (Protocol
3000)
Table 6 and Table 7 list the ASCII values to switch an input to an output for a
single VP-4x8AK machine. For more detailed information, see Protocol 3000
(
Section 14.2 ).
Table 6: VP-4x8AK Video Signal Codes for Protocol 3000
OUT 1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6 OUT 7 OUT 8
IN 1 #V 1>1 CR #V 1>2 CR #V 1>3 CR #V 1>4 CR #V 1>5 CR #V 1>6 CR #V 1>7 CR #V 1>8 CR
IN 2 #V 2>1 CR #V 2>2 CR #V 2>3 CR #V 2>4 CR #V 2>5 CR #V 2>6 CR #V 2>7 CR #V 2>8 CR
IN 3 #V 3>1 CR #V 3>2 CR #V 3>3 CR #V 3>4 CR #V 3>5 CR #V 3>6 CR #V 3>7 CR #V 3>8 CR
IN 4 #V 4>1 CR #V 4>2 CR #V 4>3 CR #V 4>4 CR #V 4>5 CR #V 4>6 CR #V 4>7 CR #V 4>8 CR
