KRAMER: SIMPLE CREATIVE TECHNOLOGY
Operating the VP-4x8AK
24
7.6 Choosing the Audio-Follow-Video or Breakaway Option
You can switch stereo audio signals in one of two ways, either:
• Audio-follow-video (AFV), in which all operations relate to both the
video and the audio channels; or
• Breakaway, in which video and audio channels switch independently
7.6.1 Setting the Audio-Follow-Video Option
To set the Audio-follow-video (AFV) option, press the AFV button:
• If the AUDIO and VIDEO configurations are the same, then the AFV
button illuminates. The audio follows the video.
• If the AUDIO differs from the VIDEO, then the TAKE and the AUDIO
buttons flash. Also, the audio outputs, which are changed, flash
1
7.6.2 Setting the Breakaway Option
in the
INPUT STATUS 7-segment display. Press the TAKE button to confirm
the modification. The audio follows the video.
To set the Breakaway option:
Press either the AUDIO (for audio control only) or the VIDEO (for video
control only) button:
• If the AUDIO button illuminates, switching operations relate to Audio,
and the 7-segment display shows the audio status
• If the VIDEO button illuminates, switching operations relate to Video,
and the 7-segment display shows the video status
7.7 The Audio Input/Output Gain Control
The audio output
2
To increase or decrease the audio gain:
signal gain is activated when the machine is in the AUDIO
or AFV mode.
1. Select the output whose audio gain you want to change.
For example, press OUT 4.
The OUT 4 button blinks and so does the respective input on the display.
2. Press the + or – button to increase or decrease, respectively, the audio gain of
the selected output.
The audio gain display lights and the audio level value shows on the display.
1 Warning that you are about to modify the audio configuration for AFV operation
2 In this section, the output also refers to the input
