VP-211K - Technical Specifications
5
Technical Specifications
INPUTS:
2 computer graphics video on 15-pin HD connectors
2 unbalanced stereo audio on 3.5mm mini audio
connectors
OUTPUTS:
1 computer graphics video on a 15-pin HD connector
1 computer graphics video on a 15-pin HD connector
(input #1 active loop)
1 unbalanced stereo audio on a 3.5mm mini audio
connector
MAX. OUTPUT LEVEL:
Video: 1.6Vpp; Audio: >10.5Vpp
BANDWIDTH (-3dB):
Video: 300MHz; Audio: >100kHz
DIFF. GAIN:
0.03%
DIFF. PHASE:
0.03Deg.
K-FACTOR:
<0.05%
S/N RATIO:
Video: 71dB; Audio: 71dB weighted
CROSSTALK:
Video:
–59dB @5MHz; Audio: <–66dB @1kHz
CONTROLS:
Contact closure remote control, Input default selection
switch
COUPLING:
DC
AUDIO THD + NOISE:
<0.032%
AUDIO 2nd HARMONIC:
<0.004%
POWER CONSUMPTION:
5V DC, 200mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95", W, D, H)
WEIGHT:
0.3kg (0.66lbs) approx.
ACCESSORIES:
Power supply (5V/2.6A), mounting bracket
OPTIONS:
RK-3T 19" rack adapter
Specifications are subject to change without notice
