VP-211K - Connecting the VP-211K
9
If the VP-211K detects:
No signal (perhaps no connected source, or a source is connected and
powered OFF) at the UXGA IN 1 input (when IN 1 is selected as the default),
the VP-211K routes the signal from the source at UXGA IN 2 to the UXGA
OUT and the AUDIO OUT connectors. Similarly, if the VP-211K detects no
signal at the UXGA IN 2 input (when IN 2 is selected as the default), the
VP-211K routes the signal from the source at UXGA IN 1 to the UXGA OUT
and the AUDIO OUT connectors
A signal from the UXGA source at UXGA IN 1 input (when IN 1 is selected
as the default), while routing the signal from the UXGA source at UXGA IN 2,
the VP-211K reroutes the signal from the UXGA source at UXGA IN 1 to the
UXGA OUT and the AUDIO OUT connectors. Similarly, if the VP-211K
detects a signal from the UXGA source at UXGA IN 2 input (when IN 2 is
selected as the default), while routing the signal from the UXGA source at
UXGA IN 1, the VP-211K reroutes the signal from the UXGA source at
UXGA IN 2 to the UXGA OUT and the AUDIO OUT connectors
No signal at all (that is, when there is no active input from a source at UXGA
IN 1 or at UXGA IN 2), the VP-211K still routes UXGA IN 2 to the UXGA
OUT, and continue to examine UXGA IN 1 input (when IN 1 is selected as
the default), switching back to it when it detects a valid signal. Similarly, if the
VP-211K detects no signal at all (when IN 2 is selected as the default), it still
routes UXGA IN 1 to the UXGA OUT, and continue to examine the UXGA IN
2 input, switching back to it when it detects a valid signal
