VM-24HC - Technical Specifications

Technical Specifications

INPUTS:

2 HDMI connectors

OUTPUTS:

4 HDMI connectors

BANDWIDTH:

Supports up to 2.25Gbps bandwidth per graphic channel

COMPLIANCE WITH HDMI
STANDARD:

Supports HDMI and HDCP

CONTROLS:

EDID SELECT, EDID READ, IN 1, IN 2 buttons, RS-232,
IR

INDICATOR LEDs:

POWER, IR, OUTPUT

POWER CONSUMPTION:

5V DC, 1.1A

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

21.5cm x 16.3cm x 4.4cm (8.5” x 6.4” x 1.7”) W, D, H

WEIGHT:

0.6kg (1.3lbs) approx.

ACCESSORIES:

Power supply

OPTIONS:

RK-

1 19” rack adapter

Specifications are subject to change without notice at
