The Router Mode Keys
18
To increase the volume, point the remote control transmitter at the remote
receiver and do the following:
1. Press the VOL+ key.
2. Press the numeral key defining the audio signal
1 continuously until the volume
increase is satisfactory.
Table 8: Audio Output Type Key for VP-26
Press key: To adjust the audio level of the:
1 VGA/UXGA 1 group
2 Video (CV) 1 group
3 s-Video (Y/C) 1 group
4 Comp 1 group
5 VGA/UXGA 2 group
6 Video (CV) 2 group
7 s-Video (Y/C) 2 group
8 Comp 2 group
9 Master audio out
10 Microphone
Decreasing the Volume of the VP-26
To increase the volume, point the remote control transmitter at the remote
receiver and do the following:
1. Press the VOL- key.
2. Press the numeral key defining the audio signal
3 continuously until the volume
decrease is satisfactory.
7.5 Controlling an Expanded Series 16x16 Matrix Switcher
You can control an expanded series 16x16 matrix switcher, using the
RC-IR2. For example, when using two VS-1616V units to form a 32x16
switcher 2 , set both VS-1616V units as MACHINE # 1 3 . Using the setup
commands, on the first VS-1616V unit, set the IR REMOTE control to ON,
and on the second VS-1616V unit, set the IR REMOTE control to OFF 4 .
When a switcher has no built-in front panel remote receiver, for example,
when using 3 VS-1604 units, set each VS-1604 unit as MACHINE # 1 and
connect an external remote receiver to the first VS-1604 unit only.
1 See Table 8. For example, to adjust the microphone audio level, press the <10> key
2 See the VS-1616V user manual, section 6.3.1 on page 12
3 As Figure 9 illustrates on page 13 of the VS-1616V user manual
4 See the VS-1616V user manual, section 8.10 on page 51
