KRAMER: SIMPLE CREATIVE TECHNOLOGY

The Router Mode Keys

12

7.3.2

Switching an Input to an Output

To switch an input to an output after assigning the machine number and group

number, do the following:
1. Press a Selector key number for the output

1

.

2. Press a Selector key number for the input.
For example, to switch INPUT 3 to OUTPUT 5 on a switcher, press <5> and

then <3> (in the single digit mode).
In the double-digit mode, press the <--> key and then <0/10>, <5> and

<0/10>, <3>.

7.3.3

The STO and RCL Keys

You can store and recall input/output configurations

2

using the selector keys.

7.3.3.1 Storing an Input/Output Configuration

To store the current status in memory, do the following:
1. Press the STO key.
2. Press one of the Selector keys (this will be the setup # in which the current status

is stored).

The memory stores the data at that reference.

7.3.3.2 Recalling an Input/Output Configuration

To recall an input/output configuration, do the following:
1. Press the RCL key.
2. Press the appropriate Selector key (the key # corresponding to the setup #).

The memory recalls the stored data from that reference.

1 When switching units categorized in group 11 and in groups 1, 2, 3, 4, 14, 15 and 16, ignore step 1 which is inapplicable to
units with just one output
2 Check the switcher’ s user manual to determine the number of configurations you can store. For example for the VP-66ETH,
you can store up to six configurations
