2. Installation
2−20
Festo P.BE−CPX−CEC−EN en 1004a
2.9 Complying with protection class IP65/IP67
In order to comply with protection class IP 65/IP67, seal unĆ
used sockets and the switch with the appropriate covers.
Connection/
switch Connection
IP65/IP67 Cover 1)
IP65/IP67
Ethernet, RJ45 Plug
type FBS−RJ45−8−GS Cover 2)
type AK−RJ45
Sub−D (CANopen/
RS232) and
DIL switch Plug type FBS−
SUB−9−BU−
2X5POL−B Transparent cover 2)
type AK−SUB−9/15−B
Service interface,
M12 Connecting cable and
plug of the CPX−MMI Protective cap 2)
type ISK−M12
Rotary switch ć Cover 2)
type AK−RJ45
1) If connection is not used
2) Included in scope of delivery
Tab. 2/8: Connections and covers for protection class
IP65/IP67
