Safety Instructions – SECTION 1
DANGER
WARNING
CAUTION
WARNING
Hazardous voltage
can shock, burn or
cause death.
Safety Instructions – SECTION 1 • Other personal protective equipment to protect against
hazardous/toxic fluid.
Maintenance Safety:
• Always lock out power.
• Ensure pump is isolated from system and the pressure
is relieved before disassembling the pump, removing
plugs, or disconnecting the piping.
• Use proper lifting and supporting equipment to prevent
serious injury or death.
• Observe all decontamination procedures.
General Information – SECTION 2
INTRODUCTION
NOTE: The information in this manual intends to be
used as a guide only. If you are in doubt, consult
your Bell & Gossett Representative for specific
information about your pump.
The design, material, and workmanship incorporated in
the construction of Bell & Gossett VTP pumps makes
them capable of giving long, trouble free service. The life
and satisfactory service of any mechanical unit, however,
is enhanced and extended by correct application, proper
installation, periodic inspection and careful maintenance.
This instruction manual was prepared to assist operators
in understanding the construction and the correct
methods of installing, operating and maintaining these
pumps.
Rotating components of the pump
assembly must be covered with a suitable
rigid guard to prevent injury to personnel.
Study thoroughly Sections 1 through 6 and carefully
follow the instructions for installing and operating.
Sections 5 contains answers to troubleshooting and
maintenance questions. Keep this instruction manual
handy for reference.
Bell & Gossett will not be liable for any
damages or delay caused by failure to
comply with the provisions of this instruction manual.
RECEIVING AND CHECKING
The pump should be carefully supported prior to
unloading from the carrier. Handle all components
carefully. Inspection for damage of the shipping crate
should be made prior to unpacking the pump. After
unpacking, visually inspect the pump and check the
following:
1. Contents of the pump assembly against the
packing list.
2. All components against damage.
3. All shafting for damage, should the crate be
broken or show careless handling. All shafting
must be checked for straightness.
Any shortages or damages should be immediately called
to the attention of the local freight agent of the carrier by
which the shipment arrived and proper notation made on
the bill. This will prevent any controversy when a claim is
made and facilitate prompt and satisfactory adjustment.
WARNING
CAUTION
General Information – SECTION 2
WARNING
CAUTION
TO AVOID SERIOUS OR FATAL PERSONAL
INJURY OR MAJOR PROPERTY DAMAGE, READ
AND FOLLOW ALL SAFETY INSTRUCTIONS IN
THE MANUAL AND ON THE PUMP.
This is a SAFETY ALERT SYMBOL.
When you see this symbol on the pump or
in the manual, look for one of the follow-
ing signal words and be alert to the poten-
tial for personal injury or property damage.
Warns of hazards that WILL cause serious
personal injury, death or major property
damage.
Warns of hazards that CAN cause serious
personal injury, death or major property
damage.
Warns of hazards that CAN cause personal
injury or property damage.
NOTICE: INDICATES SPECIAL INSTRUCTIONS
WHICH ARE VERY IMPORTANT AND MUST BE
FOLLOWED.
THIS MANUAL IS INTENDED TO ASSIST IN
THE INSTALLATION AND OPERATION OF
THIS UNIT. THOROUGHLY REVIEW ALL
INSTRUCTIONS AND WARNINGS PRIOR TO
PERFORMING ANY WORK ON THIS PUMP.
MAINTAIN ALL SAFETY DECALS.
Install, ground and wire according
to local and National Electrical Code
Requirements.
Install an all leg disconnect switch
near the pump.
Disconnect and lockout electrical
power before installing or servicing
the pump.
Electrical supply must match motor’s
nameplate specifications. Incorrect
voltage can cause fire, damage motor
and void the warranty.
Single phase pump motors are equipped with an
automatic thermal protector, which opens the motor’s
electrical circuit when an overload condition exists.
This can cause the pump to start unexpectedly.
General Precautions
Personal injuries will result if procedures
outlined in this manual are not followed
Electric supply MUST match pump’s
nameplate specifications. Incorrect
voltage can cause fire, damage to motor and voids
warranty.
Safety Apparel:
• Insulated work gloves when handling hot sand collar.
• Heavy work gloves when handling parts with sharp
edges, especially impellers.
• Safety glasses (with side shields) for eye protection.
• Steel-toed shoes for foot protection when handling
parts, heavy tools, etc.
General Precautions
