Page 7
Qty Part # Description
1
1050-0026........Complete clutch hub assembly
1
2061-0026........Steel inner hub only
1
2061-0025........Outer hub (aluminum) only
1
2057-0010........Thrust washer
1
2057-0011........Bellview washer
2
1100-0033........Screws for clutch hub
4
1100-0122........Bolts for mounting alum. plate
4
2057-0026........Stand-off hub nuts
7
1054-0005........Clutch friction plate/Kevlar
1056-0020
Fits 2006 Dyna & 2007-Up All Big Twin
Qty Part # Description
1
2061-0005 ....Steel inner hub
1
2061-0050 ....Outer hub (aluminum)
1
2057-0010 ....Thrust washer
1
2057-0011......Bellview washer
2
1100-0033......Screws for clutch hub
4
1100-0113......Bolts for clutch hub
4
2057-0026 ....Nuts for clutch hub screws
8
1054-0005 ....Clutch friction plate(s)/Kevlar
Qty Part # Description
1
2061-0005 ....Steel inner hub
1
2061-0019 ....Outer hub (aluminum)
1
2057-0010 ....Thrust washer
1
2057-0011......Bellview washer
2
1100-0033......Screws for clutch hub
4
1100-0113......Bolts for clutch hub
4
2057-0026 ....Nuts for clutch hub screws
9
1054-0004 ....Clutch friction plate(s)/Kevlar
Qty Part # Description
1
1101-0068 ....Small snap ring (hub rear)
1
1061-0004 ....Steel inner hub
1
1100-0132 ....Nut for clutch hub screw (need 4)
1
2059-0003 ....Diaphragm clutch spring (silver/medium)
1
2059-0200 ....Diaphragm spring retainer
4
2055-0001 ....Shouldered nut (retainer)(need 4)
2
1058-0106 ....Locking clip for retainer nuts (2 req)
4
2057-0023 ....Washer for nut (need 4)
1
1061-0009 ....Outer hub aluminum
1056-0006
Fits 1998-2006 Evo & Twin Cam
(except 2006 Dyna)
1056-0005
Fits 1990-1997 Evo Big Twin
1056-0003
Fits 1986-1989 Evo Big Twin
8
2060-0006 ....Clutch plate steel (.047”)
1
1060-0003 ....Clutch plate steel (.120)
1
1101-0068......Snap ring small
1
2058-0001 ....Pressure plate
1
2059-0003 ....Diaphragm clutch spring (silver/medium)
4
2057-0022 ....Shouldered nuts (for retainer)
2
1058-0106 ....Lock clips for shouldered nuts
1
2059-0200 ....Diaphragm spring retainer
1
2057-0024 ....Washer set (4 plus 4)
1
1108-0006......Installation instructions
2
2060-0003 ....Clutch plate steel (.080”)
7
1060-0004 ....Clutch plate steel (.047”)
1
2060-0004 ....Clutch plate steel (.120)
1
1101-0068......Snap ring small
1
2058-0010 ....Pressure plate
1
2059-0003 ....Diaphragm clutch spring (silver/medium)
4
2055-0001 ....Shouldered nuts (for retainer)
2
1058-0106 ....Lock clips for shouldered nuts
1
2059-0200 ....Diaphragm spring retainer
1
2057-0024 ....Washer set (4 plus 4)
1
1108-0006......Installation instructions
4
1100-0113......Bolts for clutch hub
4
2057-0027 ....Washer (stud side adjustment)(4 req)
7
1054-0012 ....Clutch friction plate
1
2060-0007 ....Clutch plate steel (.080”)
1
2058-0023 ....Pressure plate (center hump)
1
2057-0006 ....Clutch hub nut spacer
6
2060-0006 ....Steel plate (.047”)
1
1060-0003 ....Steel plate (.120”)
2
1100-0033 ....Screws for clutch hub(2)
1
1108-0006 ....Installation instructions
7
2060-0006........Clutch plate steel (.047”)
1
1060-0003........Clutch plate steel (.120”)
1
1101-0068........Small snap ring
1
2058-0001........Pressure plate
1
2059-0003........Diagraphm clutch spring (silver/medium)
1
2059-0200........Diaphragm spring retainer
4
1057-0110........Shouldered nuts (for retainer)
2
1058-0106........Lock clips for retainer nuts
1
2057-0024........Shims for clutch pack (4 large / 4 small)
1
1108-0006........Installation instructions
7
