Instructions

for

SHOVELHEAD & IRONHEAD XL

42mm Mikuni Carburetor & Manifold Kit

12450 Whittier Blvd., Whittier, CA 90602 Tel:(562) 907-2600 Fax: (562) 907-2606

www.riveraprimoinc.com

REQUIRES 1990-95 OEM BIG-TWIN STYLE THROTTLE CABLES.

THROTTLE CABLE LENGTH IS DEPENDENT UPON HANDLEBAR HEIGHT.

1108-0010 / Revised 3-08

For all Shovelhead applications 1970-1984 and all Ironhead Sportster models 1971-1985.

Pre-1971 model XL cannot be fitted due to the fact that 1958 XLCH used a magneto or distributor located directly

below the carburetor. 1954-to-1970 KH, XL, XLH, XLH-70, and XLCH have a stand-up a distributor located directly

below the carburetor.

* NOT LEGAL FOR SALE OR USE IN CALIFORNIA OR ON ANY POLLUTION CONTROLLED MOTOR VEHICLES.
