KIT PARTS LIST
Item Part no
Description Qty
1 RIV-014 Bolt 1
2 RIV-016 Lockwasher 1
3 RIV-015 Flatwasher 1
4 RIV-009A Breather dual out 1
4A RIV-009A-TC (Twin Cam only) 1
5 RIV-009 Breather one out 1
5A RIV-009-TC (Twin Cam only) 1
6 RIV-010 Spacer 2
7 RIV-006 Support bracket 1
8 SM-013 Stepped washer 2
8A SM-013-TC (Twin Cam only) 2
9 SM-19 5/16" Bolt 2
10 SM-010 1/2" Hollow bolt 2
10A SM-010-TC 3/8” Hollow bolt 2
11 ME-0048 1/4-20 Acorn Nut 2
12 RIV-005 Choke bracket 1
13 RIV-022 Spigot seal 1
14 ME-0022S A/C base 1
15 ME-0033 Air Cleaner spacer 2
16 HSR42-3003 O-ring 1
17 RIV-012 Air filter 1
18 ME-0023 A/C cover 1
19 ME-0032 A/C studs 2
20 RE-90-R Seal set 1
21 RE-90-F front flange 1
21A RE-90-R rear flange 1
22 RIV-026-A Cast manifold 1
22 RIV-026-B Polished manifold 1
22 RIV-026-C Chrome manifold 1
23 ME-0014 4mm screw 1
24 ME-0015 4mm washer 1
25 ME-0016 5mm screw 1
26 ME-0017 5mm washer 1
27 ME-0018 5mm lock-nut 1
28 RIV-004 Cable bracket 1
29 RIV-017 Fuel/breather hose 24" 1
30 RIV-020 Hose clamp 2
32 RIV-024 Spacer 1
33 ME-0038 Spacer 2
34 ME-0037 Carb Mount bolt 2
35 ME-0054 Flat Washer 1/4” 4
36 ME-0053 Lock Washer 1/4” 2
37 ME-0029 Lock Washer 5/16” 2
38 PC-015A Stainless flat washer
6
