PAGE 3 IN600 INSTALLATION AND OPERATION MANUAL
The Innovation series from AMAV is a huge step forward in the interfacing and
management of audio and visual sources. Integrating a host of smart, high end
features in a compact package that offers the end user extremely simple control
over their complex audio visual system. The Innovation series is as ground
breaking as it is simple to operate.
The IN600 takes the Innovations series concept to the next level in terms
of fl exibility and complete system control. The IN600 features an on board
mic/line mixer, 6 AV source inputs, and 6 balanced XLR outputs so it can be
confi gured as a 5.1 front end. The IN600 also features RS232 for projector
control and logic output for screen up/down control. With the IN600 we give the
AV integrator the ability to use the IN600 for full room AV control or it can be
interfaced with third party control systems if desired. The IN600 offers untold
fl exibility for AV control in an extremely user friendly package.
AUS, EUR, USA
Copyright 21st Aug 2008
REV A 21st Aug 2008
REV B 9th Dec 2008
REV C 28th May 2009
REV D 15th April 2010
REV E 3rd June 2010
INTRODUCTION AND CONTENTS
INTRODUCTION 3
FRONT PANEL 4
REAR PANEL 5
INSTALLATION 6
SETUP / SOFTWARE 7–9
INTERNAL ADJUSTMENTS 10
BLOCK DIAGRAM 11
DIMENSIONS 12
SPECIFICATIONS 13
