Rugged Ridge Fender Flare Kit, 09-14 Ford F-150 User Manual
Page 5
Copyright © 2013 Omix-Ada
®
, Inc.
460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: 770-614-6101 | FAX: 770-614-6069 | [email protected]
All Terrain Flares 09+ Ford F150
10. Follow guide shown for proper way to install Plastic
Square Tabs and Long Screw U-Clamps. Hold flare to
vehicle and attach using supplied Phillips screws into
Screw U-Clamps, starting with the topmost screws first.
11. Use a 10 mm socket wrench to reinstall factory
bolts. Complete rear flare installation.
Page 4/5
81630.04
Flare
Plastic
Tab
Vehicle
Fender
Screw U-
Clamp
Phillips
Screw
