Rugged Ridge Fender Flare Kit, 09-14 Ford F-150 User Manual
Page 2
Copyright © 2013 Omix-Ada
®
, Inc.
460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: 770-614-6101 | FAX: 770-614-6069 | [email protected]
All Terrain Flares 09+ Ford F150
3. Remove three factory installed screws with
7/32” socket wrench. Save factory screws for rein-
stallation.
1. Install supplied bolts, washers, and locking nuts into
each flare.
2. Clean inside of top lip edge with rubbing alcohol.
Install edge trim by removing red vinyl tape covering
only a few inches at a time. Applying adhesive side
of edge trim to inner side of flare. Install edge trim to
the top edge of flare (the edge that contacts ve-
hicle). Do not stretch trim while being applied. Trim
excess from ends.
Page 2/5
81630.04
Inner Flare Surface
Washer
Bolt
Nut
