All Terrain Flares 09+ Ford F150
9. Hold flare to vehicle and using a marker or
grease pencil mark locations of four holes in flare
on sheet metal. Wrap a Plastic Square Tab around
sheet metal over four marks. Install Long Screw U-
Clamps over four Plastic Square Tabs.
7. Install Retainer Rivet Screws in four marked holes.
Complete front flare installation.
8. Remove two factory bolts from bottom of rear
wheel well using a 10 mm socket. Save bolts for rein-
stallation.
Page 4/5
81630.04
