USER

’S GUIDE

switched rack pdu

19

Main menu

The main control console menu has options that provide access to the
management features of the control console:

1- Device Manager
2- Network
3- System
4- Logout

s

Device Manager option

This option accesses the Device Manager menu. Select the components
you want to manage from this menu. To do any of the following tasks, see

Device Manager Menus

:

1- Phase Monitor/Configuration

2- Phase Outlet Restriction Configuration

3- Outlet Control/Config

4- Power Supply Status

Option four not available to outlet users.

Network option

To do any of the following tasks, see

Network Menu

:

• Configure the TCP/IP settings for the Switched Rack PDU
• Use the Ping utility
• Define settings that affect the FTP, Telnet, Web interface, SNMP, e-

mail, and DNS features of the Switched Rack PDU

When you log on as Device Manager or as an Outlet User,
you will not have access to the System or Network menus.
