Link-RX/TX (10/100) LED

This LED indicates the network status.

Status LED

This LED indicates the network status of the PDU.

Condition

Description

Off

The device which connects the PDU to the network is off or not
operating correctly.

Flashing Green

The PDU is receiving data packets from the network at 10
Megabits per second (Mbps).

Flashing Orange

The PDU is receiving data packets from the network at 100
Megabits per second (Mbps).

Solid Green or
Orange

The Switched Rack PDU is receiving no network traffic.

Condition

Description

Off

The PDU has no power.

Solid Green

The PDU has valid TCP/IP settings.

Flashing Green

The PDU does not have valid TCP/IP settings.

1

Solid Orange

A hardware failure has been detected in the PDU. Contact

APC

Worldwide Customer Support

.

Flashing Orange

The PDU is making BOOTP

2

requests.

1 If you do not use a BOOTP server, see the Switched Rack PDU Installation and Quick Start

Manual provided in PDF on the APC Switched Rack Power Distribution Unit Utility CD and in
printed format to configure the TCP/IP settings.

2 To use a BOOTP server, see the Management Card Addendum (.\doc\Addendum.pdf) on the

APC Switched Rack Power Distribution Unit Utility CD.
