Page 12: User ’s guide, Switched rack pdu, Single-phase three-phase

background image

®

®

®

®

USER

’S GUIDE

switched rack pdu

8

Front Panel

Single-phase

Three-phase

Link - Rx/Tx

10 /100

Status

Serial Port

Reset

Press and hold

to invert display

- Warning

- OK

- Overload

Link - Rx/Tx

10 /100

Status

Serial Port

Reset

Press to

select line.

Press and hold

to invert display.

- Warning

- OK

- Overload

L3

L2

L1

Am

ps

Am

ps
