Load indicator LED
The load indicator LED identifies overload and warning conditions for the
displayed phase.
Condition
Description
Solid Green
The displayed phase is below the current overload
thresholds.
Yellow
The displayed phase is in a Near Overload Warning
condition. The current is above the Near Overload Warning
threshold.
Red
The displayed phase is in an Overload condition. The
current is above the Overload Alarm threshold.
