Item Number Size Description Quantity
113 1/4"-18 NPT External hex/square head
pipe plug
2
113A 1/2"-14 NPT External hex/square head
pipe plug
1
193 1/4"-18 NPT Grease fitting 2
228 - - - - Bearing frame 1
241 - - - - Frame foot 1
370F 1/2" Hex cap screw 2
408A 3/8"-18 NPT External square head pipe
plug (magnetic)
1
408J 1/4"-18 NPT External hex/square head
pipe plug
1
408L 1/2"-14 NPT Square countersunk
headless pipe plug
1
408M 1" 11-1/2" NPT Square countersunk
headless pipe plug
1
529 1/2" Light helical spring lock
washer
2
Conversion from flood-oil to pure-oil mist
Consult your local ITT representative for further information on this topic.
Convert from flood oil to regreaseable
Consult your local ITT representative for further information on this topic.
