3410 IOM 1/2010
53
7
PARTS LIST AND MATERIALS OF CONSTRUCTION
Item
Qty per
Pump
Part Name Bronze Fitted All Iron
Iron / 316
Rot. El.
All
316SS
426 var. Hex Cap Screw, Parting Steel
428 2
Gasket, Sleeve to Impeller (M, L,
and XL only)
1/32" Non-Asbestos
445A 2
Anti-Rotation Pin, Casing Wear
Ring
AISI 420 AISI 316
469G 2 Tapered Pin W/Hex Nut Steel
494 2 Cooling Assembly (Optional) Copper Tube, Fitting
497 2
O-Ring - Sleeve Nut (M, L, and XL
only)
Buna Rubber
MATERIALS OF CONSTRUCTION
Code Specification
1000 Cast Iron - ASTM A48 Class 25B
1003 Cast Iron - ASTM A48 Class 30B
1179 Bronze - ASTM B584-UNS C87600
304 Wrought Stainless - ASTM A276, Type 304
AISI 1018 ASTM A108, Grade 1018 -B1112
AISI 420 ASTM A276, Type 420
AISI 4140 ASTM A322, Grade 4140
1618 Bronze -ASTM B584 Alloy C80500
1071 Nitronic 60 - ASTM A743 Grade CF10SMnN
