PARTS LIST AND MATERIALS OF CONSTRUCTION
Item
Qty per
Pump
Part Name
Bronze Fitted
All Iron
Iron / 316
Rot. El.
All
316SS
100
1 Upper
1 Lower
Casing
1003
1003
A743 CF-8M
101
1
Impeller
1179
1000
316
316
102
2
Seal Tubing (optional)
Brass
Steel
316
103
2
Wear Ring, Casing
1618
1000
1071
105
2
Lantern Ring
Glass Filled Teflon
106
1 set
Stuffing Box Packing
Square Non-Asbestos
(Die-Formed S&M Groups)
107
2
Stuffing Box Gland
AISI 316
109
2
Bearing End Cover
1000
109A
1
Bearing End Cover - Thrust
Steel
112
1
Ball Bearing - Thrust
Steel
113
2
Grease Fitting
Steel
113A
2
Breather (Oil Lubrication Only)
Steel
122
1
Shaft
AISI 4140*
123
1
Deflector - (optional)
Laminated Plastic
124
1
Sleeve Nut (M, L, and XL only)
1618
1000
1071
125
2
Stuffing Box Bushing
316
126
2
Shaft Sleeve (optional on S group)
1618
1000
316
134
2
Bearing Housing
1000
142
2
Impeller Wear Ring
1618
1000
316
168
1
Ball Bearing - Coupling
Steel
178
1
Impeller Key
AISI 1018*
222B
4
Set Screw - Sleeve Nuts
Steel
250
2
Gland, Mech Seal
(Flush STD)***
1179
1003
1002
316
2
Gland, Mech Seal
FL-VT-DR (Optional)
Steel
251
2
Sight Oiler (Optional Oil
Lubrication)
White Metal and Glass
317
2
Magnetic Seal, Thrust (Optional)***
Steel
317A
1
Magnetic Seal, Radial (Optional)***
Steel
320
6
Retaining Set Screw - Impeller
Wearing Ring (Optional)
303 SS
332
1
Grease - Oil Seal Outboard
Buna Rubber
332A
1
Labyrinth Seal Outboard
(Optional)***
Steel
333
2
Oil Seal - I.B., Grease
Buna Rubber
333A
1
Labyrinth Seal Inboard
(Optional)***
Steel
351
1
Casing Gasket, Parting
1/32" Non-Asbestos
353
4
Studs, Gland
316
353B
2
H.C. Screw (W/C.I. Mech. Seal
Gld.)
Steel
4
H.C. Screw (W/Stl. Mech. Seal Gld.)
Steel
355
4
Hex Nut - Gland Stud
304
356A
4
Stud - Casing Parting
Steel
360
2
Gasket - End Cover to Bearing
Housing
Kraft Paper
360Q
8
Gasket - Gland to Case
Non-Asbestos
361
1
Retaining Ring, Thrust Bearing
Steel
361H
2
Retaining Ring, Impeller (S Group
only)
Steel
Stainless Steel
371C
8
Hex Cap Screw
Steel
372U
4
Hex Cap Screw
Steel
418
2
Hex Cap Screw - Casing Jacking
Steel
425
4
Hex Nuts, Parting
Steel
