Magikitch'n CG - Manual (Page 14)

L25-007 Rev. 2 12
LPG-30/60
Slide side shelf assembly onto the desired side of the unit, and install two ¼-20 screws through the shelf support and into the
frame side. Note: side shelf comes assembled for right hand applications, for left side remove spice/utility rack and
reinstall on the other side of the shelf.
LPAGA-30/60
Remove the three ¼-20 screws holding the Rear spacer bar to the shelf assembly, and discard the Rear spacer bar. Remove the
top front and rear ¼-20 screws from the trim side on the desired side of application. Slide the side shelf assembly onto the
unit, and reinstall the two ¼-20 screws previously removed from the trim side. Note: side shelf comes assembled for right
hand applications, for left side remove spice/utility rack and reinstall on the other side of the shelf.
11. Side Shelf for LPG-30/60 and the LPAGA-30/60
TRIM KIT SIDE
SIDE SHELF ASSEMBLY
REAR
SPACER BAR
10545E12.DW
