Magikitch'n CG - Manual (Page 12)

10 L25-007 Rev. 2
9. Cutting Board for the LPAGA/LPG-30
30” Richlite® Cutting Board Option Set for MagiCater, 9825-2000101.
Contents:
• (1) Left hand bracket, 5403-0989801
• (1) Right hand bracket, 5403-0989802
• (2) Screws, pan head Phillips, 1/4-20 x 3/4” long
with captive internal tooth lockwasher, 4001-
0963400
• (1) 30” Richlite ® cutting board, 3906-1192200
Remove the original 1/2” long screws from
the ends of the service shelf and use the 3/4”
long screws supplied to install the cutting
board brackets as shown here.
The cutting board lays inside the confines
of the brackets in the front and the frame
edge at the back.
