AZEK Rail User Manual
Page 12
Page 12
Installing AZEK Rail Stairs with CableRail by Feeney
®
#10 x 2”
Coated Screws
Bottom Rail
Pre-drill 3/16”
Use
Intermediate
Base Plate as
template
ATTACH STAIR INTERMEDIATE BALUSTER
PRE-DRILL BOTTOM RAIL
7
6
• Trim Stair Intermediate Baluster to match stair angle.
Screw chase
Use the Intermediate Base Plate
as a Template, as shown to the
right.
Be sure the screw fi nds
the screw chase
For easier installation,
pre-drill screw chase
with a 3/16” drill bit.
