Page 8
O
v
er
vi
e
w
Location and Function of Parts
GB
8
V VISCA RS-232C connector
Connect to the VISCA RS-232C IN connector of
the camera or the Optical Multiplex Unit.
W VISCA RS-422 connector
Connect to the VISCA RS-422 connector of the
camera or the Optical Multiplex Unit.
An RS-422 connector plug is attached at the
factory.
X TALLY/CONTACT connector
This connector is used for the tally lamp input or the
contact output.
Select the function of the connector using the
TALLY/CONTACT selector.
An RS-422 connector plug is attached at the
factory.
Y TALLY/CONTACT selector
Select the function of the TALLY/CONTACT
connector.
TALLY: The tally lamp of the camera selected
with the connected switcher lights.
CONTACT: The contact output corresponding to
the camera address selected with this unit is short-
circuited against the connected switcher.
CONTACT (TALLY): The contact output
corresponding to the camera address selected with
this unit is short-circuited against the connected
switcher and the tally lamp of the camera selected
with the connected switcher lights.
wh DC IN 12V connector
Connect the supplied AC power adaptor.
wj DIP switches (bottom)
Switch 1 (RS-232C/RS-422 selector)
Set to ON for RS-422, or OFF for RS-232C.
Switch 2 (Communication baud rate selector)
Set to ON for 38400bps, or OFF for 9600bps.
wk ON/OFF switch
Press this switch to turn on/off this unit.
Note
Set the switches before you turn on the power of this
unit. Otherwise, the setting is not effective.
Available Functions for Sony VISCA Cameras
The functions of the controls, buttons and connectors in the following list differ depending on the connected camera
model. The functions of the other parts are the same for all the camera models.
a
: available,
×
: not available
Parts
BRC-300/
300P, BRC-
H700/H700P
EVI-D100/
D100P
EVI-D70/
D70P
EVI-D30/
D30P
SNC-RZ30N/
RZ30P
B VALUE/R control
a
a
a
×
a
C BRIGHT/B control
a
a
a
×
a
G ONE PUSH AF button
a
a
a
×
a
L PAN-TILT RESET button
a
a
a
a
×
N MENU button
a
a
a
a
×
R POWER button
a
a
a
a
×
S CAMERA buttons
a
a
a
a
×
W VISCA RS-422 connector
a
×
a
Ч
Ч
