Quick-Connect PRO and WallVIEW PRO for the AW-HE120 Camera

Page 11 of 16

General Specifications

WallVIEW PRO HE100 System

Part Numbers
Without Camera:

998-6125-000: Quick-Connect CCU Kit for the AW-HE120 Camera (camera not included) - North America
998-6125-001: Quick-Connect CCU Kit for the AW-HE120 Camera (camera not included) - International

Part Numbers
With Camera:

999-6125-000K: WallVIEW PRO HE120 System with Black AW-HE120 (camera included) - North America
999-6125-000K: WallVIEW PRO HE120 System with Black AW-HE120 (camera included) - International

999-6125-000W: WallVIEW PRO HE120 System with White AW-HE120 (camera included) - North America
999-6125-001W: WallVIEW PRO HE120 System with White AW-HE120 (camera included) - International

Quick-Connect Interface

Connectors

Power Connector: 5.5mm OD x 2.5mm ID
Power RJ-45: Supplies 36V to EZIM (EZCamera Interface Module) Regulators
IR: 2-Pin Molex 5.0mm Euro-Style Connector
Video Outputs: BNC Connectors for HD Analog Component (Y,PB,PR) or Y/C and Composite
Video RJ-45: Transports HD or SD video from camera depending on Cable. System ships with HD
cable only, the SD cable is an optional accessory

Camera Select
Switch

8-Position DIP switch loads camera profiles and IR Forwarding for Polycom and TANDBERG
Codecs (IR Forwarding Not Available on AW-HE100)

Video
Adjustments

Y-Gain (luminance gain) for fine tuning over longer cable distances
Distance Compensation: 100’, 200’, 300’, 400’+

Max. Cat. 5 Cable
Distance

Up to 500’ (152.4m) for Video Power and Control

Power Supply

36 VDC, 2.78 Amp

Dimensions

1-RU Rack Mount, 1.72” (43.69mm) H x 18.93” (480.82mm) W x 6” (152.4mm) D

EZCamera Interface Module (EZIM)

Connectors

Four (4) RJ-45 Connectors (Note: RS-232 in/out does not work with the AW-HE100 camera)
One DB-25 for Power, Video, Control & IR (IR not available for AW-HE100 camera)

Cable Assemblies

For Panasonic HD Cameras: DB-25M to DB-15HD, 4-Pin XLR-F Power Connector
(8-Pin Mini Din x 2 - unused)

Power Regulator

Supplies 12VDC to Cameras

Dimensions

3.035” (76.2mm) H x 4.45” (113.03mm) W x 1.25” (31.75) D

Panasonic AW-HE100 Camera Basic Specifications

Camera Part Number

AW-HE120

CMOS Image Sensor

3CMOS 1/3” 2.2 Megapixel

Signal Systems

NTSC or PAL

Video Resolutions

1080/59.94i, 1080/50i, 720/59.94p, 720/50p, 480/60i and 576/50i. SDI (HD/SD, BNC), analog
component (D-SUB 15P) and HDMI outputs are provided. Selecting HDMI output enables
1080/59.94p and 1080/50p.

Lens

20X Optical

Weight

6.6 lbs. (3.0 kg)

Dimensions (W x H x D)

7.1” W x 9” H x 8.7” D – excluding protrusions
(180mm x 228mm x 220mm) - excluding protrusions
