Appendix 1: rs-232 control, General specifications – Vaddio ProductionVIEW HD-SDI User Manual
Page 19

ProductionVIEW HD-SDI
General Specifications:
Video Resolutions & Distances* - Inputs
Video Resolutions - Outputs
HD Resolutions:
1080p – SMPTE 424M – Max. Length: 459.3 ft. (140m) (3Gb/s compliant)
1080i – SMPTE 292M – Max. Length: 754.6 ft. (230m)
720p – SMPTE 292M – Max. Length: 754.6 ft. (230m)
HD Resolutions:
1080p – SMPTE 424M
1080i – SMPTE 292M
720p – SMPTE 292M
SD Resolutions:
480i – SMPTE 259M – Max. Length: 820.2 ft. (250m)
576i – SMPTE 259M – Max. Length: 820.2 ft. (250m)
SD Resolutions:
480i – SMPTE 259M
576i – SMPTE 259M
* Note: All cable lengths noted above are based on using Belden 1694A cable
Appendix 1: RS-232 Control
The ProductionVIEW HD-SDI has six (6) discrete camera control ports which eliminates the need for
daisy-chaining control cabling. With ProductionVIEW HD-SDI, all cabling configurations are home-run
wiring configurations. Each Channel will auto-configure the input channel for control of the camera
attached.
Vaddio uses simple control protocols to accomplish custom programming with the ProductionVIEW HD-
SDI. The Communication Specification, API and Programming Language are listed below and definitions
are listed on the next page. Note: All commands must be followed by a carriage return.
Communication Specification
Communication Speed: 9600 bps (default)
Start bit: 1
Stop bit: 1
Data bits: 8
Parity: None
No Flow control
Control Port - RS-232 on DB-9F Connector
PIN#
Signal
2)
TXD
3)
RXD
5)
GND
All other pins - Unused
ProductionVIEW HD-SDI
Part Numbers:
999-5650-000 (North America)
999-5650-001 (International)
Compatible PTZ Cameras* :
* most cameras require an optional SDI card
All Vaddio Cameras
Sony EVI-HD1V/3V/7V, EVI-100S, EVI-100V, BRC-300, BRC-Z330,
BRC-H700 & BRC-Z700, BRC-H900
Panasonic AW-HE100, AW-HE120
Canon BU-45H, BU-46H, BU-47H, BU-50H, BU-51H
Video Switcher:
6 x 2
Video Transitions:
Cross Fade, 9 Wipe options and Straight Cuts, Fade to Black
Video Inputs:
Six (6) HD-SDI / SD-SDI inputs on BNC connectors
Preview Output:
Two (2) Preview outputs (BNC) – HD-SDI or SD-SDI
Program Output:
Two (2) Program outputs (BNC) – HD-SDI or SD-SDI
External Reference:
Input for sync from external device for Gen Lock of outputs
Camera Control Ports:
Six (6) RS-232 on RJ-45F
Control Interface:
One (1) RS-232 on DB-9
8-Line LCD Display (Menu):
8 – line backlit LCD display
Power Requirements:
PowerRite 18 VDC, 2.78 Amp
Control Inputs for Auto Mode (input 1 & 2):
Cameras 1 & 2 have 6 presets each or Camera 1 can have 12
(selectable – either Tally output function works, or Control Inputs)
Tally Output:
Tally outputs for each of the six video inputs
(selectable – either Tally output function works, or Control Inputs)
Weight:
9.5 lbs. (4.32kg) – approximate weight
Dimensions (H x W x D):
16” (40.64cm) x 10” (25.4cm) x 4” (10.16cm)
ProductionVIEW HD-SDI Manual 341-852 Rev. B
Page 19 of 22
