ProductionVIEW HD-SDI
Cam Search Menu
>Select
>All Ports: (select search method – Auto, Sony, Canon, Panasonic*, No Camera**)
>Port 01: (select search method – Auto, Sony, Canon, Panasonic, No Camera)
>Port 02: (select search method – Auto, Sony, Canon, Panasonic, No Camera)
>Port 03: (select search method – Auto, Sony, Canon, Panasonic, No Camera)
>Port 04: (select search method – Auto, Sony, Canon, Panasonic, No Camera)
>Port 05: (select search method – Auto, Sony, Canon, Panasonic, No Camera)
>Port 06: (select search method – Auto, Sony, Canon, Panasonic, No Camera)
*NOTE 1: It is highly recommended that when using Panasonic cameras, to select Panasonic to speed up the
recognition of the cameras when ProductionVIEW HD-SDI is turned on.
**NOTE 2: By setting a port to “No Camera”, the ProductionVIEW will not scan that port for a camera type.
This allows for a faster boot up when a 3 or 4 camera system is used.
CCU Mode
>Select
>All Ports: (Select method – Direct Cam Ctrl or CCU)
>Port 01: (Select method – Direct Cam Ctrl or CCU)
>Port 02: (Select method – Direct Cam Ctrl or CCU)
>Port 03: (Select method – Direct Cam Ctrl or CCU)
>Port 04: (Select method – Direct Cam Ctrl or CCU)
>Port 05: (Select method – Direct Cam Ctrl or CCU)
>Port 06: (Select method – Direct Cam Ctrl or CCU)
NOTE: When Vaddio Quick-Connect CCUs are used with ProductionVIEW HD-SDI, CCU mode disables Iris
functions, AWB and BLC on the ProductionVIEW HD-SDI console, allowing the user to control these functions
from the Quick-Connect CCU)
System Menu
>Select
>Serial Input
>Select
>Yes or No
Turns on or off serial input (default is Yes)
>Serial Echo
>Select
>Yes or No
Turns Serial Echo on or off (default is Yes)
>Serial Info
>Select
>On or Off
Reports button pushes on front panel out the serial port (default is Off)
(Does not report joy stick position)
>Panel Lights
>Select
>00 through 50
Panel Light Brightness (all lights - 50 is the brightest) (default is 25, off is 00)
>Clear Memory
>Select
>Start
Clears the camera preset memories and sets all parameters to default settings
>Clear Presets
>Select
>Start
Clears the camera preset memory only
>Power Up Preset
>Select
>Home Camera
>Select - Upon power up, all cameras will go to their home position
>Preset 12
> Select - Upon power up, all cameras will go to Preset 12
