ProductionVIEW HD
ProductionVIEW HD Manual 341-759 Rev. C Page 22 of 24
Appendix 1: Command Structure Definitions
Command Parameters Description
AWB AWB On/Off(cr) Auto White Balance On/Off
BLC BLC On/Off(cr) Backlight Compensation On/Off
Camera Camera [9](cr) Select indicated camera (1-6)
CamFolPrv CamFolPrv On/Off(cr) Set Select follows Review selection On/Off
ClearAll ClearAll(cr) Clear all presets
Config Config(cr) Display system configuration
Cut Cut(cr) Select Cut Transition
DefaultCam DefaultCam [9](cr) Set default camera (1-6)
DspCams DspCams(cr) Display cameras connected(and Port)
ExtTrigger ExtTrigger AllCam1/Cam1_2(cr) Set trigger mode all on cam 1 for 6 on each
Focus Focus Up/Dn/Auto/Manual,[9] (cr) Focus Up/Dn/Auto/Manual, Value
FTB Fade U/D/(10-40) Fade To Black
Home Home(cr) Home Camera
IdleRtn IdleRtn [9](cr) Idle Return 0-60 seconds
Iris Iris Up/Dn/Auto/Manual,[9] (cr) Iris change Up/Dn/Auto/Manual, Value
JPanDir JPanDir [9],[9](cr) Set Pan Direction by Port(0,1-6), Dir(Normal/Invert)
JPanSpd JPanSpeed [9],[9](cr) Set Pan Speed by Port (0,1-6), Speed(1-24)
JTiltDir JTiltDir [9],[9](cr) Set Tilt Direction by Port(0,1-6), Dir(Normal/Invert)
JTiltSpd JTiltSpeed [9],[9](cr) Set Tilt Speed by Port(0,1-6), Speed(1-20)
JZoomDir JZoomDir [9],[9](cr) Set Zoom Direction by Port(0,1-6), Dir(Normal/Invert)
JZoomSpd JZoomSpeed [9],[9](cr) Set Zoom Speed by Port(0,1-6), Speed(0-7)
lsgDen lsgDen [9](cr) Set LSG density (0-9)
LSgSize LsgSize [9](cr) LSG Size (0-3)
Mix Mix(cr) Select Mix/FTB mode
Move Move(Up/Down/Left/Right/Stop)(cr) Move camera
OnCamInit OnCamInit Home/Preset12(cr) Set initialization preset Home camera or content of preset12
PanSpeed PanSpeed [9](cr) Set Preset Pan Speed
PipLoc PipLoc [9], [9](cr) Select Pip location (0-3), Size (0-2)
Power Power On/Off(cr) Power system On/Off
Preset Preset [9](cr) Select indicated preset (1-12)
PresetLoc PresetLoc Local/InCam (cr) Set Preset location 6 in cam 6 in system, All in system
PrevIn PrevIn [9](cr) Select Preview input(1-6)
ProgIn ProgIn [9](cr) Select Program input(1-6)
Rescan Rescan(cr) Initiate Camera scan
Reset Reset(cr) Soft System reset
ResetVideo ResetVideo(cr) Re-Load Video Configuration
Save Config SaveConfig(cr) Saves configuration of all console settings
SerialEcho SerialEcho On/Off(cr) Serial Echo On/Off
SerialInfo SerialInfo(On/Off)(cr) Serial Information mode on/off
SetDefault SetDefault [9](cr) Set default Preset (1-12)
Store Store [9](cr) Store indicated preset on the current camera(1-12)
SwMode SwMode Single/Dual(cr) Select operating mode Single/Dual switcher(s)
SysMode SysMode Auto/Manual(cr) System Access automatic/Manual
Take Take(cr) Initiate Transition
Tally Tally High/Low(cr) Non-selected(Idle) tally level
TiltSpeed TiltSpeed [9](cr) Set Preset Tilt Speed
Version Version(cr) Display System Version information
Wipe Wipe(cr) Select Wipe Transition
WipeSel WipeSel [9](cr) Select Wipe (0-11)
Zoom Zoom (in/Out/Stop)(cr) Zoom Camera
ZoomSpeed ZoomSpeed [9](cr) Set Preset Zoom Speed
