ProductionVIEW HD Manual 341-759 Rev. C Page 20 of 24
General Specifications:
Input Video Resolutions
HD Resolutions:
1080i
59.94
1080i 50
720p 59.94
720p 50
1080p 59.94 *
1080p 50 *
SD Resolutions:
480i NTSC - Composite or Y/C
576i PAL - Composite or Y/C
RGBHV Resolutions**: H. Freq (kHz) Pixel Clock (MHz)
640 x 480 @ 60Hz - VGA 31.5 27.175
640 x 480 @ 75Hz - VGA 37.5 31.5
800 x 600 @ 60Hz - SVGA 37.879 40
1024 x 768 @ 60Hz - XGA 48.363 65
1024 x 768 @ 75Hz - XGA 60.023 78.750
1280 x 768 @ 60Hz 47.776 79.5
1280 x 1024 @ 60Hz - SXGA 63.981 108
1366 x 768 @ 60Hz - WXGA 47.775 67.43
1400 x 1050 @ 60Hz - SXGA+ 65.359 115
1600 x 1200 @ 60Hz - UXGA 75 162
Output Video Resolutions
HD Resolutions:
1080i
59.94
1080i 50
720p 59.94
720p 50
1080p 59.94 *
1080p 50 *
SD Resolutions:
480i NTSC - Composite or Y/C
576i PAL - Composite or Y/C
RGBHV Resolutions**: H. Freq (kHz) Pixel Clock (MHz)
640 x 480 @ 60Hz - VGA 31.5 27.175
640 x 480 @ 75Hz - VGA 37.5 31.5
800 x 600 @ 60Hz - SVGA 37.879 40
1024 x 768 @ 60Hz - XGA 48.363 65
1024 x 768 @ 75Hz - XGA 60.023 78.750
1280 x 768 @ 60Hz 47.776 79.5
1280 x 1024 @ 60Hz - SXGA 63.981 108
1366 x 768 @ 60Hz - WXGA 41.571 74
1400 x 1050 @ 60Hz - SXGA+ 65.340 121.75
1600 x 1200 @ 60Hz - UXGA 75 162
1920 x 1200 @60 HZ – WUXGA*** 74.038 154
***With reduced blanking (with monitor support on VGA input)
* Support of 1080p component video (YPbPr) required on third-party equipment
** Certain equipment my not supply appropriate resolutions, and therefore may not function properly
ProductionVIEW HD
Part Numbers:
999-5600-000 (NTSC)
999-5600-001 (PAL)
Compatible Cameras: Vaddio, Panasonic, Sony & Canon (see page 3 for specific models)
Video Formats Supported: NTSC and PAL
Video Switcher: 6 x 2
Video Transitions: Cross Fade, 9 Wipe options and Straight Cuts, Fade to Black
Video Inputs: Six (6) RGBHV, HD Component (YPbPr), Y-C or Composite (DE-15F)
Preview Output:
Two (2) Preview outputs (DE-15F) -- Y-C, Composite or HD
Component (YPbPr) or RGBHV using breakout cables – same
resolution on both outputs
Program Output:
Two (2) Program outputs (DE-15F) -- Y-C, Composite or HD
Component (YPbPr) or RGBHV using breakout cables – same
resolution on both outputs
Camera Control Ports: Six (6) RS-232 on RJ-45F
Control Interface: One (1) RS-232 on DB-9F
LCD Display: 8 - Line Backlit LCD Display
Power Requirements: PowerRite 18 VDC, 2.75 Amp
Control Inputs for Auto Mode (input 1 & 2): Cameras 1 & 2 have 6 presets each or Camera 1 can have 12
Tally Output: Tally outputs for each of the six video inputs
Weight: 9.5 lbs. (4.32kg) – approximate weight
Dimensions (H x W x D): 16” (40.64cm) x 10” (25.4cm) x 4” (10.16cm)
