Analog Audio Input (2) Selectable Microphones/Lines
(10) Microphone Inputs
Phantom Power +24.0 VDC
Analog Audio Output – 1 Output Channel
– Line Level, Variable, 100
Ω
Termination
Signal to Noise >80dB
(Line Level Throughput)
Frequency Response
20-15,000 Hz
Control Interfaces
Front Panel Push Button Mic/Line, Master/Slave, Switching Mode
Serial Remote Control COMM1 (Rear Panel 9-Pin D, Male) RS-232D
Mixer Link RJ-11-6, Straight Through Cable
Audio Connections Removable 5.5mm Circular Connectors
Power Requirements 12 VDC, 750mA External Plug-in, Universal
AC Input Supply
Weight 3.54lbs/1.6kg
Dimensions
Depth 6.25”/15.9cm
Width 16.75”/42.6cm
Height 1.75”/4.45cm
Power Supply 12 VDC, 750mA
8.) Adjust the 5-Band Graphic Equalizer for best sound quality for the application by
turning the control to the left or right.
OPERATION
• Voice Activated – Turn on all microphones. Turn OFF Push-To-Talk mode (light
OFF). adjust the Gate Threshold so the ambient noise does not cause a micro-
phone to trigger. One configured for voice activated mode, there is no need for
user intervention. The loudest voice gets control.
• Push-To-Talk (PTT) – Set all microphones to Push-To-Talk (PTT). Turn ON PTT
mode on the MicVIEW (light ON). Adjust the threshold. In PTT mode, a user must
press the PTT button on the microphone and speak into the microphone. When the
user is finished speaking, the user must release the PTT button.
Setting Up the
MicVIEW
(continued)
Care and
Cleaning
• Do not attempt to take this device apart. There are no user-serviceable parts
inside.
• Keep this device away from food and liquid.
• To clean the exterior, wipe with a damp cloth. Do not use abrasive chemicals.
Do not store or operate this device under the following conditions:
• A temperature above 104
o F (40 o C) or below 32 o F (0 o C)
• Environments with high humidity
• Dusty environments
• In inclement weather
• Under severe vibration
Operating and
Storage
Conditions
Technical
Specifications
3
4.) If the MicVIEW is to be used with an external system where it is necessary to
know which microphone is active such as the Vaddio ControlVIEW, connect the
Microphone Logic Outputs to the corresponding input connections on the external
device.
5.) Press the Push-To-Talk button to switch between Push-To-Talk mode (light ON)
and Voice Activated mode (light OFF).
6.) Adjust the Gate thresholds to set the gating for optimum performance by turning
the screw terminal to the left or right to adjust sensitivity. For Push-To-Talk mode,
adjust the Low Gate threshold and for Voice-adtivated mode, adjust the High Gate
threshold.
7.) Adjust the Input Level adjustments to adjust the volume of each microphone.
