11. SPECIFICATIONS
Input Power 115 Volt/ 60Hz, 115 Volt/ 50Hz, 230 Volt/ 60 Hz, or 230 Volt/
50Hz
Input Current 200ma nominal, 2 amperes (short circuit)
Stroke Length Control 0 – 100% control range
Resolution – 0.0625% increments
Stroke Adjustment response Approximately 1% per second
Analog Input
Operating Range 0 to 25.5mA (4-20 mA factory default)
Input Impedance 160 ohms
Minimum Span 2.0 mA
Isolation 500V from all other inputs, outputs and ground, optically
isolated
Conditioning 8 second running average.
Split Ranging and Reverse Acting accessible via calibration.
Analog Output
Operating Range 0 to 25.5mA (4-20 mA factory default)
Maximum Load 700 ohms
Minimum Span 2.0 mA
Conditioning None. Output represents current stroke position.
Split Ranging and Reverse Acting accessible via calibration.
Isolation 500V from all other inputs, outputs and ground, optically
isolated.
Status Input
Motor On/Off Optically isolated dry contact input. Open contact indicates
motor is off. Controller will then suspend all stroke control
action. Motor starter should provide a contact for connection
here.
Environmental
Rated Ambient Temperature -20
°C to 40°C (-4°F to 104°F)
Storage Ambient Temperature -25
°C to 60°C (-13°F to 140°F)
Enclosure NEMA4, IP66, NEMA 4X
Approvals UL/ULC - NEMA 4X
CE – IEC EN 61010-1
Transient Voltage Max Impulse withstand 1500V (115VAC Models), 2500V
(230VAC Models) at 50uS
Voltage Overload 120% Continuous,
Pollution Degree Suitable for Pollution Degree 3
Input Voltage 115 (105-125 acceptable range) or 230 (208 – 240 acceptable
range) VAC
Note: factory configured only for correct input voltage range
(specified at time of purchase) Single phase input only 50 or 60
