4 housing access – Pulsafeeder Pulsar ECA NEMA4X User Manual
Page 15
6.4 Housing Access
All wiring and programming of the ECA must be accomplished through the removal of the
housing cover. Use this procedure for removal and replacement:
Cover Removal
• Disconnect power at the source (follow your local Lock-Out-Tag-Out procedures).
• Disconnect power at the source.
• Loosen and remove the 4 Phillips head screws which secure the rear cover.
• Grasp the cover and lift straight up.
Figure 1
Cover Re-installation
9
