Merrychef 402s - Manual (Page 18)

402s Ovens Pt. No. 32Z3522 Issue 6
18
Part number identification chart 1
Ref. No. Description Part No.
1 Cavity High limit Stat 30Z1024
2 Motor Start Capacitor 2µF ( Blue ) 30Z1298
3 Filter 16A 30Z1340
4 Air filter SA276
5 Stirrer motor Assembly SA288
5A Stirrer (inside cavity) SA291
6 Microswitch SW1, SW2, SW3, SW4 30Z1294
7 Door Hinge Assembly RH SA202
8 Magnetron Cooling Fan 30Z1295
9 Door Hinge Assembly LH SA203
10 Motor Controller 30Z1293
11 Fuse 10A HRC 30Z0217
12 Gold resistor ( 220R ) 30Z0235
13 Relay PCB Assembly 11K0004
14 Ribbon Cable 15way 11Z0298
15 Ribbon Cable 10way MenuKey 11M0117
16 Logic PCB Assembly Version 2.0 SA231
16 Logic PCB Assembly Version 3.0 SA260
17 Transformer LT (Low voltage) 30Z1155
18 Fuse 1A 30Z0957
19 Cable Gland 31Z0500
Cable Gland Nut 31Z0499
20 Heater Element 208V 650W DV0576
Heater Element 220V 650W DV0606
Heater Element 240V 650W DV0607
21 Magnetron 30Z1349
22 Magnetron Thermistor Assembly SA234
23 Convection ( Hot Air ) Motor Assembly SA208
24 Thermistor Cavity 30Z1315
25 HV Capacitor 2500V 0.88μF ( 60Hz Models ) 30Z1251
25A HV Capacitor clip 31Z1261
27 Transformer 208/220/240V 60Hz 30Z1230
28 HT Rectifier 11H0010
29 Electrical Supply Lead Assembly SA217
30 Terminal Block 31Z0447
31 Fuse 20A FLM 30Z1177
32 Fuse Holder 30A 30Z1178
34 Fuse Holder 10A 30Z0231
35* Grease Filter ( 2 parts ) SA339
SA340
5B Stirrer Gear DV0552
6A Microswitch Assembly SA212
20A Heater Element Collar DV0058
