46
Actiontec DSL Modem User Manual
47
Chapter 5 Configuring Advanced Settings
Priority
Select either “High” or “Normal” for the priority level of the type of data traffic
being configured.
Protocol
Select the data protocol type being configured here. Click on the down arrow to
reveal the options:
ALL , TCP , UDP , GRE , ICMP .
Set IP Precedence
To activate IP Precedence, click in the appropriate box. Once activated, the user can
set the IP precedence level of the traffic being configured by clicking on the down
arrow and selecting an option level from 1 (low priority) to 7 (high priority).
Source
Select the “Source” type (“ IP ” for IP address, “ MAC ” for MAC address) here, then
enter the IP or MAC address in the text box to the right. If IP was selected, enter a
netmask address in the appropriate text box. The user can also set a port range .
Destination
Select the “Destination” type (“ IP ” for IP address, “ MAC ” for MAC address) here,
then enter the IP or MAC address in the text box to the right. If “ IP ” was selected,
enter a “netmask” address in the appropriate text box. The user can also set a port
range.
Rule List
Once a QoS priority rule is configured, click Add. The rule will appear in the “Rule
List” text box. The user can add more rules to this list, or remove a rule by select-
ing it, then clicking Remove.
