BP500

Transforming the Control of Hot Tubs

43

Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,

834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.

Adjusting Filtration

FILT1: Main Filtration

Filter cycles are set using a start time and a duration. Start time is indicated by
an “A” or “P” in the bottom right corner of the display. Duration has no “A” or
“P” indication. Each setting can be adjusted in 15-minute increments. The panel
calculates the end time and displays it automatically.

FILT2, Filter Cycle 2: Optional Filtration

Filter Cycle 2 is OFF by default.

It is possible to overlap Filter Cycle 1 and Filter Cycle 2, which will shorten overall
filtration by the overlap amount.

Purge Cycles

In order to maintain sanitary conditions, secondary Pumps and/or a Blower

t

will purge water from their respective plumbing by running briefly at the
beginning of each filter cycle.
If Filter Cycle 1 is set for 24 hours, enabling Filter Cycle 2 will initiate a purge

t

when Filter Cycle 2 is programmed to begin.

Pump Purge default time is 60 seconds.
Blower Purge default time is 30 seconds.

The following pages describe how to set up filtration times.

READY

RANGE FLTR1

JETS

AUX

LIGHT

HEAT

JETS

AUX

LIGHT

HEAT
