BP500

Transforming the Control of Hot Tubs

17

Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,

834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.

Dual Temperature Ranges

The BP500 system incorporates two temperature range settings that allows an
independent set temperature within each range. The High Range is designated
in the display by an “up” arrow, and the Low Range is designated in the display
by a “down” arrow.
These ranges can be used for various reasons, with a common use being a
“ready to use” setting vs. a “vacation” setting. Each range maintains its own set
temperature as programmed by the user. This way, when a range is chosen, the
spa will heat to the set temperature associated with that range.
t High Range can be set between 80°F and 104°F.
t Low Range can be set between 50°F and 99°F.
t Freeze Protection is active in either range.

If no key activity occurs, main menu returns in 5 seconds.

t

More specific temperature ranges may be determined by the manufacturer.

t

READY

RANGE FLTR

READY

RANGE FLTR1

RANGE FLTR1

READY

READY

RANGE FLTR1

The water temperature display will show

whether the system is in High or Low Range.

Low Range Arrow

High Range Arrow
