BP500

Transforming the Control of Hot Tubs

39

Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,

834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.

READY

RANGE FLTR1

JETS

AUX

LIGHT

HEAT

JETS

AUX

LIGHT

HEAT

Pumps, Operation (cont.)

Press the “Jets 1” button once to turn pump 1 on or off, and to shift between low
and high speeds if equipped.
If left running, the pump will turn off after a time-out period.

The pump 1 low speed will time out after 30 minutes.

t

The high speed will time out after 15 minutes.

t
On non-circ systems, the low speed of pump 1 runs when the blower or any
other pump is on. If the spa is in Ready Mode, Pump 1 low may also activate for
at least 1 minute every 30 minutes to detect the spa temperature (polling) and
then to heat to the set temperature if needed. When the low speed turns on
automatically, it cannot be deactivated from the panel; however, the high speed
may be started.
