Acer 5510 - Manual (Page 95)

89 Chapter 6
OPTICAL DEVICE
HOLDER-FIX ZL1A DVD HOLDER
(FIX) ASSY S.P. 42.T51V7.003
DVD DUAL BEZEL G
BASE ZL1 DVD DUAL BEZEL
ASSY W/P (GB) S/P 42.A51V7.005
DVD KME SUPMU ASS
W/P W/O MB ZL2 KME SUPMU ASS
W/P W/O MB STN B/S S/
P 6M.A76V7.001
DVD SUP MUL DRIVE
KME UJ-840BAA-A ZL7 DVD SUP MUL UJ-
840BAA-A S/P KU.00807.011
OPTICAL DEVICE
HOLDER-FIX ZL1A DVD HOLDER
(FIX) ASSY S/P. 42.T51V7.003
DVD SUPER MULTI
BEZEL G BASE ZL2 SUPER MULTI
BEZEL (HLDS)W/P S/P 42.A65V7.002
DVD DUAL MODUEL
PHILIPS ZL7 QSI DUAL ASSY W/
P W/O MB S/P 6M.A76V7.002
DVD/RW DUAL PHILIPS
SDVD8441 ( QSI SDW-
082K) ZL7 DVD RW(DUAL)
SDVD8441 L-F S/P KU.00803.006
OPTICAL DEVICE
HOLDER-FIX ZL1A DVD HOLDER
(FIX) ASSY S/P. 42.T51V7.003
DVD DUAL BEZEL G
BASE ZL1 DVD DUAL BEZEL
ASSY W/P (GB) S/P 42.A51V7.005
DVD DVD DAUL
MODULE KME UJ-845
DL SLOT IN 6M.A65V7.002
DVD DVD DUAL DRIVE
KME UJ-845 DL SLOT IN KU.00807.015
OPTICAL DEVICE
HOLDER 42.T51V7.003
DVD DVD DUAL BEZEL
FOR KME SLOT IN 42.T63V7.005
DVD DUAL MODUEL
PIONEER ZL2 PIO DVD DUAL ASS
W/P W/O MB(SLOT)B/S
S/P 6M.A65V7.003
DVD DUAL DRIVER
PIONEER KO5RA ZL3 DVD DUAL (K05RA)
SLOT-IN S/P KU.00805.013
OPTICAL DEVICE
HOLDER-FIX ZL1A DVD HOLDER
(FIX) ASSY S/P. 42.T51V7.003
DVD DUAL BEZEL FOR
PIONEER SLOT IN ZL3 SLOT BEZEL ( PIO )
ASSY S/P 42.A63V7.003
HDD/Hard Disk Drive
40G SEAGATE 2.5 IN.
4200RPM
N2.2ST9402112A F/
W:3.01 KH.04001.014
40G TOSHIBA 2.5 IN.
4200RPM PLUTO
MK4025GAS (ROHS) F/
W KA100A KH.04004.005
Parts
Illustration Part Name Description Acer P/N
