Chapter 6

84

Item

Description

Item

Description

1

LCD bezel

11

Lower case without media bay

2

LCD hinge(left)

12

CPU cover w/ TV tuner assy

3

LCD hinge(right)

13

DDR cover

4

LCD cover

14

HDD bracket

5

Middle cover

15

HDD cover

6

Upper case

16

DVD dual assy

7

VGA support plate

17

Mainboard C/S CIR only

8

VGA sink

18

Battery

9

CPU support

19

TV tuner board

10

M29 thermal module

20

Mainboard mylar
