NXC-VAI4 Analog Voltage Control Card
33
NetLinx Cardframe, Control Cards, and NetModules
NXC-VAI4 Output Level Assignments
NXC-VAI4 Output Level Assignments
Leve
l
Description
1
8 bit field; sets voltage on Output 1 to the value commanded.
The range is 0-255.
Conflicts with channels 1, 5, 10, 14, 18, 22.
2
8 bit field; sets voltage on Output 2 to the value commanded.
The range is 0-255.
Conflicts with channels 2, 6, 11, 15, 19, 23.
3
8 bit field; sets voltage on Output 3 to the value commanded.
The range is 0-255.
Conflicts with channels 3, 7, 12, 16, 20, 24.
4
8 bit field; sets voltage on Output 4 to the value commanded.
The range is 0-255.
Conflicts with channels 4, 8, 13, 17, 21, 25.
5
8/16 bit field; commands that Output 1 be set to "CURRENT OUTPUT 1 SPEED" of the appropriate
polarity until the voltage read at Input 1 is within "INPUT 1 MAXIMUM DEVIATION" of this value.
Conflicts with channels 1, 5, 10, 14, 18, 22.
6
8/16 bit field; commands that Output 2 be set to "CURRENT OUTPUT 2 SPEED" of the appropriate
polarity until the voltage read at Input 2 is within "INPUT 2 MAXIMUM DEVIATION" of this value.
Conflicts with channels 2, 6, 11, 15, 19, 23.
7
8/16 bit field, commands that Output 3 be set to "CURRENT OUTPUT 3 SPEED" of the appropriate
polarity until the voltage read at Input 3 is within "INPUT 3 MAXIMUM DEVIATION" of this value.
Conflicts with channels 3, 7, 12, 16, 20, 24.
8
8/16 bit field, commands that Output 4 be set to "CURRENT OUTPUT 4 SPEED" of the appropriate
polarity until the voltage read at Input 4 is within "INPUT 4 MAXIMUM DEVIATION" of this value.
Conflicts with channels 4, 8, 13, 17, 21, 25.
