NXC-I/O10 Input/Output Control Card
16 NetLinx Cardframe, Control Cards, and NetModules
Pinouts, Signals, and I/O Mode Functions
NXC-I/O10 Channel Assignments
NXC-I/O10 Pinouts, Signals, and I/O Mode Functions
Pin Signal SW mode Functions VO mode functions
1 Common Signal ground Common #1
2 I/O #1 Input #1 Input #1
3 Common Signal ground Common #2
4 I/O #2 Input #2 Input #2
5 Common Signal ground Common #3
6 I/O #3 Input #3 Input #3
7 Common Signal ground Common #4
8 I/O #4 Input #4 Input #4
9 Common Signal ground Common #5
10 I/O #5 Input #5 Input #5
11 Common Signal ground Common #6
12 I/O #6 Input #6 Input #6
13 Common Signal ground Common #7
14 I/O #7 Input #7 Input #7
15 Common Signal ground Common #8
16 I/O #8 Input #8 Input #8
17 Common Signal ground Common #9
18 I/O #9 Input #9 Input #9
19 Common Signal ground Common #10
20 I/O #10 Input #10 Input #10
NXC-I/O Channel Assignment
Channe
l
Description
1-10 Represent I/O channels 1-10
