Using Device tabs to configure the security gateway
Issue 4 May 2005 67
Figure 20: Interface tab
Config Media interfaces can be assigned to one of six different network uses, called zones. The
number of zones that can be configured depends on the security gateway model (
Table 6 ).
Ethernet0 and Ethernet1 are present in all models and are assigned to the public and the
private zones. The media interfaces that remain are unused and can be configured as required.
Table 6: Network zones
Media
type SG5 and
SG5X SG200 SG203 SG208
Ethernet0 Public Public Private Private
Ethernet1 Private Private Public Public
1 of 2
