Monitoring your network
264 Avaya VPNmanager Configuration Guide Release 3.7
Table 25: Active Ports Parameters
Parameter/
Group Description
Active Ports The number of active ports on this security
gateway.
Traffic Rate
Table Group See Traffic Rate Table Parameters on
page 264 .
Overview
Statistics Table
Group See Overview Statistics Table Parameters on
page 265 .
Ethernet
Statistics Table
Group See Ethernet Statistics Table Parameters on
page 266 .
Table 26: Traffic Rate Table Parameters
Parameter Description
Traffic Port
Description A description of each port.
Traffic Port
Index The index of this port. Indices are: Private = 0
or 2, Public = 1 or 3 (2 and 3 appear only for
the security gateway-100).
Traffic Port
Interface Index The ifIndex value from the MIB-II if Table.
Summary
Interval A time interval used to average this traffic rate.
Packets From
Port The average rate (in packets per second) at
which packets have been transmitted from this
port over the last
Packets To
Port The average rate (in packets per second) at
which packets have been received on this port
over the last
1 of 2
