Configuring VPN objects
160 Avaya VPNmanager Configuration Guide Release 3.7
Export procedure
Exporting a VPN Object involves copying the object data to a file, then sending the file to the
extranet administrator, who will import the file into their VPN Domain.
To export a VPN Object:
1. Move to the Configuration Console window.
2. From the Icon toolbar, click VPN to list all VPN Objects in the Contents column.
3. From the Contents column, select the VPN Object that needs to be configured.
4. From the Tools menu, select Export VPN to open the Export VPN dialog.
5. From the list box, select the VPN Object you want to export.
6. Click OK to open the Export VPN password dialog.
7. In the Password text box, type in a password to protect the exported data.
8. From 1 to 16 characters can be used.
9. In the Retype text box, type in your password to confirm it.
Administrator
B
creates security gateway Object
B
and supplies the IP
address of that object to Administrator
A
.
Administrator
A
creates IP Group Object
B
( Creating a New IP Group on
page 97 ) and configures it with an extranet device ( To configure an IP
Group that is associated with an extranet: on page 102 ) having the IP
address supplied by Administrator
B
.
Administrator
A
creates security gateway Object
A
( Configuring a security
gateway on page 57 ).
Administrator
A
creates IP Group Object
A
( New IP Group on page 98 )
and configures it with security gateway Object
A
.
Administrator
A
creates VPN Object
A
( Creating a new VPN object ) and
configures it with IP Group Object
A
and IP Group Object
B
.
Administrator
A
exports VPN Object
A
data to Administrator
B
( Exporting a
VPN object to an extranet on page 158 ).
Administrator
B
imports VPN Object
A
data into Domain
B.
( Importing a
VPN object from an extranet on page 161 )
Table 9: VPN Object Export Checklist (continued)
Task
2 of 2
