Installation/Operation Supplement
F232145 (EN) 32
Instructions for B Series
Microcomputer
NOTE: Opening the coin box while in Run Mode
and before a cycle has started will put control into
Audit Mode. Display will show “Audt”. To revert
back to Run Mode, close coin box and press START
keypad.
1. Turn on main power source (circuit breaker).
2. Push button and turn handle clockwise to open.
Refer to Figure 31.
Figure 31
3. Load to capacity whenever possible. DO NOT
OVERLOAD. Refer to Figure 32.
Figure 32
4. Close door and turn handle counterclockwise
until button pops out. Refer to Figure 33.
Figure 33
5. The default wash cycle will display. Refer to
Figure 34.
NOTE: Perm Press Cold is the default cycle for
coin models if none is selected. Perm Press Hot is
the default cycle for OPL models.
U001I
U003I
U001I
U005I
CHM1764C
Figure 34
CHM522N
WASH
ADD
BLEACH
RINSE
SPIN
DOOR
CLEAN
FILTER
NORMAL
LIGHT SOIL
UNIFORMS HEAVY SOIL
STAINED DELICATE
HOT
HOT
HOT HOT
HOT
HOT
WARM
COLD
START
PERM PRESS
VISA TM
CHM522N
60C 60C
40C 40C
95C 95C
< <
30C
